Realacc X210 4mm Frame + F3 6 DOF + 4X Racerstar BR2205 2300KV Motor + 4X RS30A V2 Blheli_S ESC + 7 Pairs Kingkong 5X4X3 Prop
Items Specifications Features Realacc X210 FPV Racing Frame
Full 3K Carbon Fiber frame.
35x35mm board, 30mm mounting holes.
MPU6050 Accelerometers and Gyroscopes
4 x 4 pin JST-SH Socket (I2C, SWD, 2xuart)
2 x 8 pin JST-SH Socket (PPM, PWM, SERIAL RX, GPIO, ADC, 3V, 5V, GND)
8 x 3 pin though-holes for pin headers for ESC / Servo connections.
2 x 4 pin though-holes for the 2x serial ports .
2 x 2 pin though-holes for battery voltage and buzzer.
Racerstar Racing Edition BR2205 2300KV 2-4S Brushless Motor
Model: RS30A V2
Input Voltage: 2-4S
Net Weight: 6.26g
Chips on EFM8BB21F16, 48MHZ Greatest .
BLHeli_S is designed for superior performance in multirotors, and uses hardware generated motor pwm for smooth throttle response and silent operation.
Small size combined with light weight for easy installation.
The code supports regular 1-2ms pulse width input, as well as Oneshot125 (125-250us), Oneshot42 (41.7-83.3us) and Multishot (5-25us).
The input signal is automatically detected by the ESC upon power up.
All codes use damped light mode.Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling
The code supports features to prevent sync loss. There are tuneable parameters that can make the code run well even in the most demanding situations, although default settings will work
excellently in normal operating environments
The code also supports a beacon functionality, where the ESC will start beeping after a given time of zero throttle. This can be very useful for finding lost crafts.
7 Pairs Kingkong 5X4X3 5040 5 Inch 3-Blade Rainbow Colorful Propeller
Color: Red, Orange, YelloW, Green, Pink, Purple and Black
Quantity: 7 Pairs (One Pair Each Color)
Mounting Hole: 5mm
Size: 140*140*65 mm
1 x F3 Flight Control
2 x 8p Wire Rod
2 x 4p Extension Path
5 x Pins set
2 x BR2205 2300KV Brushless Motor CW
4 x Racerstar RS30A V2 30A ESC
7 x 5040 CW Propellers
7 x 5040 CCW Propellers
