This AIO F4 FC is suitable for a lighter 2S whoop drone, like 65X,75X etc. It integrated a Betaflight F411 processor FC, Betaflight OSD, SPI Frsky receiver and 1-2S 5A ESC. So the 2S drone could save many weight for a faster fly experience.
Specification:
Brand name: SKYSTARS
Item name: TinyFrog 75X 2019 FPV freestyle Racing Drone BNF
Wheelbase: 75mm
Input voltage: 2S
Specification:
Brand name: SKYSTARS
Item name: TinyFrog 75X 2019 FPV freestyle Racing Drone BNF
Wheelbase: 75mm
Input voltage: 2S
AIO CRAZYFROG F4 TinyFrog 2S Flight Controller w/ 5A ESC & Compatible Frsky SPI Receiver
Camera: Runcam Nano2 Camera
VTX: Skystars 25-100MW 5V Version
ESC: SKYSTARS 15A Blheli_S ESC 2-4S
Motor: Skystars ST1103 11000KV
Propeller: Gemfan 40mm
Battery: 300MAH 35c 2S
Battery: 300MAH 35c 2S
| Specification | |
| CRAZYFROG F4 TinyFrog 2S Flight Controller |
CPU: STM32F411CEU6 (100MHZ )
Six-Axis: MPU-6000 triaxial accelerometer / triaxial gyroscope (SPI connection)
Size: 26mm x 26mm, fully compatible with the all whoop drone mounting pattern, recommend the TinyFrog75X frame.
Firmware version: betaflight_matekf411rx_4.0.0 (Development Version)
OSD: Built-in BetaFlight OSD (STM32 controls OSD chip over SPI in DMA mode)
Built in SPI Frsky D16 protocol native receiver, compatible with almost ALL Frsky FCC radios(e.g. Taranis X9D/X9D Plus/X7) or Frsky compatible transmitter module. Not compatible with Frsky LBT protocol.
Power Cable: 50mm, with AMASS XT30 connector
Weight: 4.5g
DIAGRAM FOR F4 2S AIO FC (BUILT-IN FRSKY RX)
|
| 5A ESC |
Built-in ESC with 5A continuous and peak 6A current
Power supply: 1-2S
Support BLHeliSuite programmable
Factory firmware: S_H_50_REV16_7.HEX
Signal Support: D-shot150, D-shot300, D-shot600, Oneshot125, Multishot, PWM
Status LED
There are 3 LEDs on the bottom of the board to indicate the status, including Receiver LED ( Green), FC Status LED ( Red ) and FC Power LED ( Blue ).
|
| Frsky SPI Receiver |
Currently the built in Frsky receiver is compatible with Taranis, Taranis Plus, X9E, Horus X12S, XJT Modules. Pay attention, this is a SPI connection receiver. In Betaflight Configuration, it should be setted as FRSKY_D receiver (aka Frsky D8 mode) or FRSKY_X receiver (aka Frsky D16 mode) in SPI RX mode.
The Frsky D16 unstable connection issue is totally resolved since Betaflight 3.4.1. Nowadays, the default configuration from factory is Frsky D16 mode (FRSKY_X).
Note: If you are using EU-LBT firmware radio controller, you might find that you can't bind successfully to this SPI Frsky receiver. Here are the solutions we provide for you.
Binding Procedure
The binding procedure is reversed as usual. No need to click the bind button when power on.
Power on the board, either by connecting the battery or USB power. Then the green receiver LED start to flash.
The second step, click the bind button for 3s. Then the green receiver LED will be solid on. This means that the receiver is in bind mode and you could start to bind your radio transmitter.
For detail procedure of binding, please check the SPI Frsky Receiver Binding Manual.
|
| Runcam Nano2 Camera |
Image Sensor: 1/3" CMOS Horizontal Resolution: 700TVL Lens: 2.1mm(M8) FOV 155° Signal System: NTSC / PAL S/N Ratio: >50dB Electronic Shutter Speed: Auto Auto Gain Control (AGC): Auto Min. Illumination: [email protected] D-WDR: Auto Day/Night: Color Power: DC 3-5.5V Current: 110mA@5V Housing Material: ABS Net Weight: 3.2g Dimensions: L14mm*W14mm*H16mm |
Package Included:
1 x TinyFrog 75X 2019 AIO 1-2S SPI Frisky receiver FPV freestyle Racing Drone
1 x 300MAH 35c 2S battery
