Overview:
The SKY04L is lite version(also LCOS version) of SKY04 series.
With focus adjustment, 1280*960 high resolution LCOS screen , the screen have vivid color , pilot can see more details in the racing .
With steadyview receiver , the receiver merge two signals to one, avoid image tearing and rolling, make image more stable and clear in challenging condition.
The new designed optics have focus adjustment feature and 39 degree field of view, give pilots more immersive FPV experience.
The new OS with 10 languages to set select, pilot have no trouble with the menu system, with shuttle wheel and new user interface, pilot can set all the settings just by rolling the wheel without taking off the goggle.
Specifications:
Brand Name: Skyzone
Item Name: SKY04L
Color: White
Screen: LCOS
Resolution: 1280X960
FOV(Diagonal): 39°
Aspect Ratio: 4:3/16:9
Focus: -6~+6 adjustable
Interpupillary Distance(IPD): 58-71mm
Receiver: 5.8Ghz 48CH Steadyview Receiver
Language: 10 Language
Power Supply: DC 6.5-25.2V/USB 5V
Power Consumption: 720mA at 12V
DVR: H264, 30fps,MOV 6Mbps, SD Card support up to 128Gb
Head Tracker: 3-axis Accelerometer, 3-axis gyroscope
Dimentions: 185*75*67mm
Weight: 267g
Features:
- 5.8G 48CH steadyview receiver
- Focus Adjustment -6~+6
- FOV 39°
- LCOS 1280*960 High Resolution Screen
- Dual Module Bay
- Bulit-in with de-fogging and heat-sink fan
- IPD range 58ã71mm
- Channel scanning
- Type C connector to upgarde the firmware or power goggle
- HDMI in
- 2S-6S wide voltage support
- Build in Headtracker
- H.264 DVR, SD card support up to 128GB
English Manual, Click Here
Package Included:
1x SKY04L Goggles
1x Steadyview Receiver Module
2x Faceplate (wide and narrow)
1x Sponge
1x Zipper case
1x Power cable
1x Headtracker cable
2x 5.8GHz 2dB antennas
1x Video/Audio Cable
1x USB-C Cable
1x Uer Manual
