Summer Prime Sale Happymodel Sailfly-X 105mm Crazybee F4 PRO 2-3S FPV Racing Drone BNF - 100.00 €

Summer Prime Sale Happymodel Sailfly-X 105mm Crazybee F4 PRO 2-3S FPV Racing Drone BNF
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


Summer Prime Sale Happymodel Sailfly-X 105mm Crazybee F4 PRO 2-3S FPV Racing Drone BNF

Specificaiton:
Brand Name: Happymodel
Model: Sailfly-X
Item Name: 105mm Crazybee F4 PRO 2-3S Micro FPV Racing Drone
Version: Compatible Frsky Receiver
- Frsky version support both NON-EU and EU-LBT Frsky transmitter
Wheelbase: 105mm
Size: 95mm*95mm*50mm(without propellers)
Weight: 35g(without battery)
Weight:60g(with Original 3s 300mah Lipo battery )

Crazybee F4 PRO Flight Controller
(Frsky version) CRAZYBEE F4FR PRO V2.1 Firmware target: CrazybeeF4FR
MCU:STM32F411CEU6 (100MHZ, 512K FLASH)
Sensor: MPU-6000(SPI connection)
Board size: 28.5 * 28.5MM
Power supply: 2-3S battery input (DC 7.4-13V)
Built-in 5A(each) Blheli_S 4in1 ESC Dshot600 ready
Frsky version Built-in SPI Frsky receiver with telemetry(D8/D16 switchable)
telemetry(AFHDS/AFHDS2A switchable)
Built-in Betaflight OSD(SPI Control)
Built-in Current meter Max 28A
Current meter scale set to 1175
Built-in 5V 1A BEC with LC filter
Built-in voltage detection
EX1102 8500KV Motor

Mode: EX1102 8500KV
Configu-ration:9N12P
Stator Diamter:11mm
Stator Length:2mm
Shaft Diameter:Φ1.5mm
Motor Dimension(Dia.*Len):Φ13.5mm*16mm
Weight(g):2.8g
No.of Cells(Lipo):2S-3S
Onboard 5A 4in1 ESC

MCU upgraded to EFM8BB21
Power supply: 2-3S LiPo/LiPo HV (7.4v/13v)
Current: 5A continuous peak 6A (5 seconds)
Support BLHeliSuite programmable
Factory firmware: S_H_50_REV16_7.Hex
Default protocol: DSHOT600
Onboard Frsky Receiver Version

SPI BUS receiver
Frsky D8/D16 switchable
Compatible both Non EU and EU-LBT transmitter Channels: 8ch or 16ch
EU-LBT support(need to update betaflght v4.0 date 2019-04-11)
Failsafe support
No ground interference ( Transmitter and receiver 1 m from the ground): 300m
40CH 25mW VTX AIO 700TVL Camera
Output power: 25mw
Frequency: 40CH
Input voltage: 3.3V 5.5V
Current consumption: 300mA(type)
Camera resolution: 700TVL
Field of view: 120°
Video Format: NTSC
Antenna: RG178 antenna
Frequency: 5.8GHz 5bands 40 channels
With Raceband
Smartaudio ready(Frsky EU-LBT and DSMX version not compatible)
Size: 13.9"12.0mm ( L*W )
Weight: 3.2g
Lipo Battery ( All Version have)
Capacity:300mAh
Voltage:11.4v
Continuous Discharge Rate: 30C
Instantaneous discharge rate: 60C
Size: 65mmx18mmx11mm
Weight: 25g
Connector: XT30

Package Included:
1x Sailfly-X FPV Racing Drone
1x 3D Printed 30 Degree Angle Canopy ( Red)
1x 3D Printed 40 Degree Angle Canopy ( Purple)
1x 3S 11.4v 300mah 30C/60C battery
1x Propeller disassemble tool
1x Screwdriver
