Sunrise Siskin BLHeli-32 11A SB 2-3S ESC With 5V/2A SBEC For RC Airplane Multicopters Racer
Description:
Brand Name: Sunrise
Item Name: BL-32 11A SB
Working Voltage: 2-3S LiPo
Con. Current: 11A
Peak Current(10s): 15A
LBEC: No
SBEC: 5V/2A
Resolution: 1480 steps
PWM Output Frequency: 24KHz
Max Supports Motor RPM: 450,000 rpm (2 poles), 150,000 rpm (6 poles)
Programming: Yes
Weight: 2g
Size(PCB): 25x10mm
Application: Suitable for RC Airplanes with about 600mm wingspan, RC Multicopters and RC Racer.
Features:
- Use 32-bit ARM Cortex MCU STM32F051 48MHZ microprocessor.
- Precise speed control, accurate signal acquisition.
- Fast response, good throttle linear performance.
- Adaptive Motor Timing, can compatible with more motors.
- Automatically detect whether it is a normal remote control signal (PWM) 50-500Hz or One-Shot125 signal.
- With synchronous rectification technology (effective life function), improve the work efficiency of ESC.
- With anti-blocking protection. When the motor or propeller is blocked, the ESC will immediately stop the rotation of the motor to avoid damage to the motor. When it is detected that there is no obstruction, the motor will start to rotate automatically.
- Regenerative braking, active braking.
English Manual,
Package Included:
1x Sunrise Siskin BLHeli-32 11A SB ESC
