Specification:
Brand Name: T-Motor
Model: F15
Item Name: 110mm F4 3-4S 3 Inch Toothpick FPV Racing Drone
Version: PNP ( Without Receiver, Lipo Battery, Radio Transmitter)
Wheelbase: 110mm
Size: 140x142x38mm
Weight: 67g ( without battery)
|
F4 OSD Flight Controller AIO ESC ( FC Diagram Picture) |
MCU: STM32F411
Gyroscope: MPU6000
BEC: 5V/2.5A with LCfilter
OSD: Built-in
Firmware: MATEKF411
Receiver: support Frsky(xm,xm+,R9mm),Flysky,TBS Crossfire Nano,DSM2/X
Support programmable LED
Built-in current sensor
Invert and non-invert SBUS port
|
| 12A BLheli_S 4in1 ESC ( Onboard) |
Input Voltage: 2- 4S HV Lipo (7.4-17.4V)
Continue Current: 12A
Burst Current: 15A
Firmware: BLHELI_S
Default Protocol: DShot600
Betaflight ammeter Settings: Scale:750, Offset:0
Motor Connectors: 1.25mm header pins connector
Size: 33×33mm (mounting hole 26.5mm)
Weight: 4.7g (W/O battery wire)
|
| T-motor F15 4500KV Motor |
Brand Name: T-Motor Model: F15 Item Name: 1106 4500KV Motor KV: 4500KV Configuration: 9N12P Shaft Diameter: 1.5mm Dimension: 14.4x13.3mm |
| HQProp T3020 & T3025 3-Blade Propeller |
Brand Name: HQProp Model: T3020 & T3025 Color: Tranparent Grey Quantity: 4 CW & 4 CCW ( 2 Pairs Per Type) |
|
5.8G 48CH 25/100/200/400mW VTX ( VTX Manual) |
Output Power: PIT/25/100/200/400mW Switchable Control Mode: BFOSD Control ( RX) Input Power: 5V Video System: NTSC/PAL Antenna: IPEX Size: 12.4x12.4x3.5mm Weight: 0.7g Frequency: 5.8GHz 6 Bands 48 Channels - with Raceband: 5362-5845MHZ |
| Runcam Nano 2 FPV Camera |
Brand Name: Runcam Model: Nano 2
Item Name: 700TVL 1/3 CMOS FPV Camera
Image Sensor: 1/3" CMOS
Horizontal Resolution: 700TVL
Lens: 2.1mm(M8) FOV 155°
Signal System: NTSC / PAL
S/N Ratio: more than 50dB
Electronic Shutter Speed: Auto
Auto Gain Control (AGC): Auto
Min. Illumination: [email protected]
D-WDR: Auto
Day/Night: Color
Power: DC 3-5.5V
Current: 110mA@5V
Housing Material: ABS
Net Weight:: 3.2g
Dimension: 14x14x16mm ( LxWxH)
|
Package Included:
1x T-Motor F15 110mm FPV Racing Drone
1x Battery Strap ( 125x10mm )
1x Non-Slip Battery Mat ( 35x15mm)
