TopMotor TH2306 2306 2600KV Brushless Motor 3-5S Red For RC Drone FPV Racing Multi Rotor
Description:
Brand name: TopMotor
Item name: TH2306 2306 2600KV Brushless Motor
KV: 2600KV
Color: red
Configu-ration: 12N14P
Stator diameter: 23mm
Stator length: 6mm
Shaft diameter: 5mm
Motor dimension (Dia.*Len): φ28.5*18.8mm
Weight: 35g
Idle current (10)@10V (A): less than 2.4
No.of cells(Lipo): 3S~5S
Max continuous power (W) 180S: 801
Internal resistance: 36mΩ
Max current (108S): 50.06A
Max effciency current: (8.69-25.57A)>81%
Screw thread: clockwise
Package included:
1 x TH2306 2306 2600KV Brushless Motor red
1 x Motor nut
1 x Motor nut
