URUAV Lemur 220mm FPV Racing Frame Kit 5mm Arm Support RunCam Micro Swift Foxxer Arrow Micro Camera
Description:
Brand name: URUAV
Item name: Lemur 220mm Racing Frame
Wheelbase: 220mm
Material: carbon fiber & aluminium alloy
Frame arm thickness: 5mm
Upper plate thickness: 2mm
Blue aluminium alloy bottom plate thickness: 3mm
Plywood plate thickness: 2mm
Standoffs: M3*30mm
Frame weight: 83g
Recommend parts (package doesn't included):
Brushless motor: 2204/2205/2206 (mounting holes: 16*19mm)
Brushless ESC: 20A-30A
Flight controller: F3 / F4 (mounting holes: 20*20mm / 30.5*30.5mm)
Camera: RunCam Micro Swift / Foxxer Arrow Micro (width: 19*19mm)
Battery: 14.8V 4S 1500mah
Propeller: 5 inch
The following products in our website are suitable for this Lemur 220mm racing frame:
Brushless motor: Racerstar BR2205 2300KV 2-4S Motor Or Racerstar SPROG X 2206 2300KV 3-4S Motor
Brushless ESC: Racerstar RS20Ax4 4 in 1 Blheli_S ESC Or Racerstar RS30A Blheli_S 2-4S ESC
Flight controller: F3 Acro 6 DOF/Deluxe 10 DOF Or F4 AIO OSD 5V BEC Current Sensor
Brushless motor: Racerstar BR2205 2300KV 2-4S Motor Or Racerstar SPROG X 2206 2300KV 3-4S Motor
Brushless ESC: Racerstar RS20Ax4 4 in 1 Blheli_S ESC Or Racerstar RS30A Blheli_S 2-4S ESC
Flight controller: F3 Acro 6 DOF/Deluxe 10 DOF Or F4 AIO OSD 5V BEC Current Sensor
Or Racerstar StarF3S 30A BL_S 4 In 1 ESC w/ F3 AIO OSD BEC Current Sensor
Camera: RunCam Micro Swift 2 Or RunCam Micro Swift Or Foxeer Arrow Micro Pro Or Foxeer Arrow Micro V2
Lipo battery: AHTECH Infinity 4S 14.8V 1500mAh 85C Graphene Or Eachine 4S 14.8V 1500mAh 75C Or Gaoneng GNB 14.8V 1500mAh 4S 120C/240C
5 inch propeller: DALPROP T5045C Cyclone Or LDARC 5045 3-Blade Or Racerstar Fish Bone 5041 3 Blade
Camera: RunCam Micro Swift 2 Or RunCam Micro Swift Or Foxeer Arrow Micro Pro Or Foxeer Arrow Micro V2
Lipo battery: AHTECH Infinity 4S 14.8V 1500mAh 85C Graphene Or Eachine 4S 14.8V 1500mAh 75C Or Gaoneng GNB 14.8V 1500mAh 4S 120C/240C
5 inch propeller: DALPROP T5045C Cyclone Or LDARC 5045 3-Blade Or Racerstar Fish Bone 5041 3 Blade
Package included:
1 x Lemur 220mm Racing Frame
1 x 5V 12V PDB
