Description:
This item is for a rapid charger / discharger for all kind of battery of RC hobby, with built in balancer for lipo battery. Battery that can be charged by this charger, Lipo / Li-ion / LiFe / NiMh / NiCad / Pb / Lead Acid
Main Features:
High-power and high-performance circuit
Microprocessor controlled
Maximen safety: Delta-peak sensitivity, capacity limit, processing time limit, tempreture limit, input power monitor
Monitoring the voltage of individual cell
Can charge Li-ion / LiPo / LiFe 1-6 cells, and Ni-Cd / NiMH 1 - 15 cells
Dual power, built-in AC adapter
Undefined large range of charge currents
Store function, allows safe storage current, and data storage (Store up to 5 packs in memory)
Battery break in and cycling
Built-in temperature sensor
Separate voltage detector for balance charge mode
Specifications:
Oeration voltage range: DC 11.0 - 18.0 Volt or AC 100V - 240V 50 / 60Hz
Circuit power: AC to DC adaptor (DC 11.0 - 18.0V / 5A)
Max. charge power: 80W
Max. discharge power: 5W
Charge current range: 0.1 - 6.0A
Discharge current range: 0.1 - 2.0A
Current drain for balancing Li-Po: 300mAh / cell
NiCd / NiMH battery cell count: 1 - 15 cell
Li-Ion / Polymer cell count: 1 - 6 series
Pb battery voltage: 2V - 20V
This item is for a rapid charger / discharger for all kind of battery of RC hobby, with built in balancer for lipo battery. Battery that can be charged by this charger, Lipo / Li-ion / LiFe / NiMh / NiCad / Pb / Lead Acid
Main Features:
High-power and high-performance circuit
Microprocessor controlled
Maximen safety: Delta-peak sensitivity, capacity limit, processing time limit, tempreture limit, input power monitor
Monitoring the voltage of individual cell
Can charge Li-ion / LiPo / LiFe 1-6 cells, and Ni-Cd / NiMH 1 - 15 cells
Dual power, built-in AC adapter
Undefined large range of charge currents
Store function, allows safe storage current, and data storage (Store up to 5 packs in memory)
Battery break in and cycling
Built-in temperature sensor
Separate voltage detector for balance charge mode
Specifications:
Oeration voltage range: DC 11.0 - 18.0 Volt or AC 100V - 240V 50 / 60Hz
Circuit power: AC to DC adaptor (DC 11.0 - 18.0V / 5A)
Max. charge power: 80W
Max. discharge power: 5W
Charge current range: 0.1 - 6.0A
Discharge current range: 0.1 - 2.0A
Current drain for balancing Li-Po: 300mAh / cell
NiCd / NiMH battery cell count: 1 - 15 cell
Li-Ion / Polymer cell count: 1 - 6 series
Pb battery voltage: 2V - 20V
Specification
Dimension and Weight |
Package weight: 0.4500 kg
Package size (L x W x H): 17.00 x 15.00 x 6.00 cm / 6.69 x 5.91 x 2.36 inches |
|---|---|
Package Contents |
Package Contents: 1 x Imax B6 LiPo Battery Balance Charger, 3 x Set of Wire, 1 x English Manual |
