Racerstar 3650 Sensorless Brushless Waterproof Motor 60A ESC For 1/10 Monster Truck Truggy Cars
Description:
Motor Features:
- 4 pole 12 slot hi-torque motor design
- CNC machined 6061 T6 billet aluminum heatsink can
- High purity copper windings maximizes efficiency
- High RPM ABEC 5 oversized bearings
- Universal fit, fits all 1/10 brushless cars; multi-mounting system for M3 screws
- Precision balanced rotor, smoothness for best reliability and maxium RPM
- Stator- super thin (0.35mm) laminations
- Removalbe/replaceable rotor
- Precision engineered for maxium energy coversion
Motor Specification:
Watts: 900
Max Voltage: 13V(3900KV), 16V(3100KV), 22V(2300KV), 24V(2050KV)
Max Amps: 69A(3900KV), 56A(3100KV), 41A(2300KV), 38A(2050KV)
Rotor Poles: 4
Max RPM: 50000
Length: 50mm
Diameters: 36mm
Weight: About 180g
Shaft: 3.17mm
Length of Extend Shaft: 15mm
Connector: 4.0mm Gold
ESC Features:
- Specially desighed for RC car with excellent start-up, acceleration and linearity feartures
- Compatible with sensorless brushless motor
- The strong resistant current capability, excellent heat dissipation
- Multiple protection features: low voltage cut-off protection for lithium or nickel battery / over-heat protection / throtttle signal loss protection / motor blocked protection
- Easily programmed and compatible with pocket-sized program card
ESC Specifications:
Model 25A 35A 45A 60A 80A 120A Cont. Current/
Burst Current 25A/100A 35A/120A 45A/180A 60A/320A 80A/480A 120A/600A Motor Type Sensorless Brushless Motor Suitable Car 1/18, 1/16 1/18, 1/16, 1/14 1/10 1/10 1/8 1/8 Suitable Brushless Motor ≥12T ≥12T ≥9T ≥9T ≥5.5T ≥3.5T Resistance 0.004ohm 0.003ohm 0.0014ohm 0.0007ohm 0.0005ohm 0.00035ohm Battery 2 cells Lipo
4-6 cells NiMH 2-3 cells Lipo
4-9 cells NiMH 2-3 cells Lipo
4-9 cells NiMH 2-3 cells Lipo
4-9 cells NiMH 2-4 cells Lipo
4-12 cells NiMH 2-6 cells Lipo
4-18 cells NiMH BEC Output 5V/2A
(analog mode) 5V/2A
(analog mode) 5.8V/3A
(switch mode) 5.8V/3A
(switch mode) 6.1V/3A
(switch mode) 6.1V/3A
(switch mode) Dimension 25*30*14.5mm 25*30*18.5mm 32.5*34*24mm 32.5*34*24mm 41*51*36mm 41*51*36mm Waterproof Level Splash-proof
For ESC program card, please click
Package Included:
1 X Motor
1 X ESC
2 X Instruction
