Waveshare DIY Micro:bit Metal 4DOF RC Robot Arm Kit With Digital Servos - 64.00 €

Waveshare DIY Micro:bit Metal 4DOF RC Robot Arm Kit With Digital Servos
Seller: Banggood,
Ship from: CN Warehouse, Usually dispatched in 1-3 work days.

FREE SHIPPING: 10-35 days. (DHL faster please check price/quantity first)
Free shipping aviable, Registered postage from 25 €


Overview
Equip your micro:bit with this 4-DOF metal robot arm, and get started to explore the world of artificial intelligent robotic.
This starter robotic arm kit includes: servo driver board, metal mechanical arm structure, and 4x metal gear servos. When used with the micro:bit, it is easy to control the arm by smart phone through Bluetooth connection.
The Servo Driver
Adopts Servo Driver for micro:bit:
- micro:bit edge connector, directly pluggable
- I2C controlled, using only 2 pins
- Up to 16-Channel servo/PWM outputs, 12-bit resolution for each channel (4096 scales)
- Integrates 5V regulator, up to 3A output current, can be powered from battery through VIN terminal
- Standard servo interface, supports common used servo such as SG90, MG90S, MG996R, etc.
- Reserved I2C control pins, allows to work with other control boards
- Comes with development resources and manual (micro:bit graphical examples like Bluetooth/2.4G wir eless remote control)
The Robot Arm Structure:
- 4-DOF, large solid base, metal mechanical grasper
- Full aluminium alloy body, sandblasting oxidation surface, strong & durable
- Clever mechanical structure and mounting design, agile to control, easy to build
- Fitted with 4x metal gear servos (1x MG996R, 3x MG90S), large torque force, smooth moving

Manual and APP source, other information, click here!
Package:
1* Robot Kit
1* MG996R Servo
3* MG90S Servo
1* MG996R Servo Plate
1* 5V 3A Adapter
1* 150MM Servo Wire
2* Screwdriver
1* Scerw Set
Control Board(selectable)
